Low pressure Fulham hose nozzles generally to BS 3016. Accept 8 mm (5/16″) bore tubing. For Natural Gas and LPG.
6246, Fulham Gas Hose Nozzle – 1/4″ BSP TM x 10mm
Fulham Gas Hose Nozzle – 1/4″ BSP TM x 10mm
Part number: 6246
Low pressure Fulham hose nozzles generally to BS 3016. Accept 8 mm (5/16″) bore tubing. For Natural Gas and LPG.
6245, Fulham Gas Hose Nozzle – 1/8″ BSP TM x 10mm
Fulham Gas Hose Nozzle – 1/8″ BSP TM x 10mm
Part number: 6245
Low pressure Fulham hose nozzles generally to BS 3016. Accept 8 mm (5/16″) bore tubing. For Natural Gas and LPG.
8843, 3 WAY HOSE NOZZLE – 90°
Hose Nozzle 3 Way 90° – 10mm o.d.
Part number: 8843
Low pressure Fulham hose nozzles generally to BS 3016. Accept 8 mm (5/16″) bore tubing. For Natural Gas and LPG.
8842, 3 WAY HOSE NOZZLE – 60°
Hose Nozzle 3 Way 60° – 10mm o.d.
Part number: 8842
Low pressure Fulham hose nozzles generally to BS 3016. Accept 8 mm (5/16″) bore tubing. For Natural Gas and LPG.
8844, 4 WAY HOSE NOZZLE
Hose Nozzle 4 Way 90° – 10mm o.d.
Part number: 8844
Low pressure Fulham hose nozzles generally to BS 3016. Accept 8 mm (5/16″) bore tubing. For Natural Gas and LPG.
8862, BOILING RING DOUBLE BURNER
Large Boiling Ring, Double Burner – Cast Iron
Part number: 8862
Boiling ring double burner – for LPG only (Propane or Butane).
The inlet connection is a 10 mm nominal diameter nozzle.
The boiling rings are supplied unassembled, assembly requires a screwdriver and a few minutes.
Rating: with 0.8 mm jets as supplied, Propane & Butane: 17060 Btu, 5.0 kilowatts.
24035, BOILING RING, SINGLE POT TRIPLE BURNER
Boiling Ring, Single Pot Triple Burner – Cast Iron
Part number: 24035
Manufacturer’s part number: CA-GB17
Cast iron support frame and three independently operated burners to give control from simmer to fast boil.
Note: For outdoor use only.
0.8mm jets.
Rating: Propane: 9.2 kW.
19537, LARGE BOILING RING SINGLE BURNER
Large Boiling Ring, Single Burner – Cast Iron
Part number: 19537
Large boiling ring single burner – for LPG only (Propane or Butane).
The inlet connection is a 10 mm nominal diameter nozzle.
The boiling rings are supplied unassembled, assembly requires a screwdriver and a few minutes.
Large boiling ring, steel support frame with cast iron burner.
Rating : with 1.3 mm jet as supplied, Propane and Butane : 18 769 Btu, 5.5 kw.
22744, BOILING RING SINGLE BURNER with FFD
Boiling Ring, Single Burner with FFD – Cast Iron
Part number: 22744
The inlet is a 10mm nominal diameter nozzle. Control tap and push button flame failure device with thermocouple. The boiling ring is supplied fully assembled.
Propane and Butane : 2.5 kW (8,530 Btu/h).
Rating : with 0.8mm jet as supplied.
For LPG only (Propane and Butane).
8861, BOILING RING SINGLE BURNER
Boiling Ring, Single Burner – Cast Iron
Part number: 8861
Boiling ring, single burner – for LPG only (Propane or Butane).
The inlet connection is a 10 mm nominal diameter nozzle.
The boiling rings are supplied unassembled, assembly requires a screwdriver and a few minutes.
Rating : With 0.8 mm jet as supplied, Propane & Butane : 8530 Btu, 2.5 kilowatts.
Dimensions: 10.1/4″ x 10.1/4″ x 3.3/4″ (260 x 260 x 95 mm)
Two Pack Automatic Changeover Kit with OPSO
Two Pack Automatic Changeover Kit with OPSO
700H to EN 16129.
Kit comprises one automatic changeover regulator with OPSO, two 20″ rubber pigtails – high pressure hose to (and marked) EN 16436-1 Class 3, POL connectors incorporating excess flow and non-return valves, one 1/2″ M x F shut-off valve with test point, wall mounting bracket and emergency instruction plaque.
11725, POL Nut Spanner Forged Steel – Black
Part number: 11725
Black forged steel spanner to fit POL and butane nuts as found on the cylinder end of pigtails, regulators and other equipment.
